| MOQ: | 1pcs |
| Delivery Period: | within 3days |
| Payment Method: | T/T, Western Union, MoneyGram |
| Supply Capacity: | 10pcs |
feature
1.Strong,firm and stable design
2.Userfriendly 'soft touch' LED membrance control panelor touch screen can be selected
3.Top & bottom pneumatic clamps to secure magazine rack
4.No PCB breakage guaranty beause of special gas circut design
5.Automatical diagnosing fault code display function
6.Durable cable and have long service life
7.SMEMA compatible
Technical parameters
| description | This equipment is used fo operate the upper board or lower boardof the circuit board on SMT production line |
| No.of Mzgazine | Upper Conveyor:1 magazine lower conveyor; 1 mazagine |
| Time feed | seconds 6Approx.or specify |
| Mazagine change over time | Approx.30 seconds or specify |
| Indexing pitch | 10.20.30.40mm or specify |
| Power supply | AC 110 volts or 220 volts; single phase |
| Power | Max300VA |
| Air prssure and Air consumption | 4-6bar,10ltr/min max |
| Transport height | 900±20MM (or customer specified ) |
| Transport direction | From left to righ or right to left |
Specification
| Model | Dimension(L*W*H MM) | PCB size(MM) | Rack size | Weight(KG) |
| ULF-M-TN | 1150*1150*1205 | 50*50-330*250 | 355*320*563 | 160KG |
| ULF-L-TN | 1350*1350*1205 | 50*50-445*330 | 460*400*563 | 220KG |
| ULF-LL-TN | 1550*1550*1205 | 50*50-530*390 | 535*460*563 | 280KG |
|
|
