| Place of Origin: | Japan |
| Brand Name: | Fully automatic storage machine |
| Model Number: | BC-M-TN |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Delivery Time: | within 3days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 10pcs |
| Brand: | KINGFEI | Part Name: | Fully Automatic Storage Machine |
|---|---|---|---|
| Part Number: | BC-M-TN | PCB Size（mm）: | 350x80~250 |
| Overall Dimensions L * W * H (mm): | 430x765~1250 | Power Supply And Power: | AC220V±10v,50/60HZ |
| High Light: | Fully Automatic SMT Storage Machine,BC-M-TN SMT Storage Machine,PLC Control SMT Storage Machine |
||
Main function
This unit is placed bewteen SMT equipments as a buffer with 20pcs PCB storage capability
Feature
1.PLC control system
2.HMI control panel,easier operation
3.20 PCBs storing capability
4.Store NG PCBs automatically according to the signal of previours equipment
5.Build in recall function for contol the order of PCB pass in and out
6.FIFO(First in first out),LIFO(last in first out)and pass throughfunction
7.Standard SMEMA
Standard machines with *
| Specifications/Type | *BC-M-TN | BC-L-TN | BC-LL-TN | BC-XL-TN |
| Supply Voltage | AC220V/50/60HZ | AC220V/50/60HZ | AC220V/50/60HZ | AC220V/50/60HZ |
| Supply air pressure | 5kgf/cm2 | 5kgf/cm2 | 5kgf/cm2 | 5kgf/cm2 |
| PCB size (mm) | 350x80~250 | 460x80~330 | 535x80~390 | 535x80~460 |
| PCB transportation direction | Left to right (right to left selection) | Left to right (right to left selection) | Left to right (right to left selection) | Left to right (right to left selection) |
| Lifting step distance of material rack (mm) | 10,20,30,40 | 10,20,30,40 | 10,20,30,40 | 10,20,30,40 |
| Transfer height (mm) | 920±30(std) | 920±30(std) | 920±30(std) | 920±30(std) |
| Transmission speed | 10m/s | 10m/s | 10m/s | 10m/s |
| Main motor power (w) | 120 | 120 | 120 | 120 |
| Overall dimensions L * W * H (mm) | 430x765~1250 | 502x855~1250 | 610x905~1250 | 610x965~1250 |
| Weight (kg) | 180 | 220 | 250 | 280 |
