| MOQ: | 1pcs |
| Delivery Period: | within 3days |
| Payment Method: | T/T, Western Union, MoneyGram |
| Supply Capacity: | 10pcs |
feature
1.User friendly membrane control panel
2.Increase board without interference
3.By pass mode provided
4.Top & bottom pneumatic clamps to secure magazine rack
5.No PCB breakage guaranty beause of special gas circut design
6.Vacwum Loader and pallet conveyor compatible
7.SMEMA compatible
Technical parameters
| description | This unit is used for automatic loadina operafion of double Sidedboards and transceiver board |
| No.ofmapazine | Upper Conveyor:1 magazine lowar conveyori 2mazagine |
| Indexing pitch | 10 20.30.40mm or specify |
| Power supply | 400pcs(0.6mm thick PCB) |
| Cycle time | Approx.12seonds or specify |
| Power supply | AC 110 volts or 220 volts; single phase |
| Power | Max 300VA |
| Air prssure and Air consumption | 4-6bar,30ltr/min max |
| Transport height | 900±20MM (or customer specified) |
| Transport direction | From left to righ or right to left |
Specification
| Model | Dimension(L*W*H MM) | PCB size(MM) | Rack size | Weight(KG) |
| CL-M-BN | 1850*855*1250 | 50*50-330*250 | 355*320*563 | 190KG |
| CL-LL-BN | 2320*994*1250 | 50*50-460*390 | 535*460*563 | 260KG |
video
|
|
