| MOQ: | 1pcs |
| Standard Packaging: | Paper pack |
| Delivery Period: | within 1~5days |
| Payment Method: | T/T, Western Union, MoneyGram, MoneyGram, MoneyGram, MoneyGram, MoneyGram |
| Supply Capacity: | 100000pcs |
Megger Instrumentation and devices Anti static system engineering
Insulation resistance tester (or high voltage insulation meter) is a special instrument for measuring insulation resistance. It is an ideal test instrument for measuring insulation resistance of large transformers, transformers, generators, high-voltage motors, power capacitors, power cables, arresters, etc.
| The Output Voltage | Measuring Range | Precision | Short circuit current |
| 250V | 1MΩ -10GΩ | ±(5%+10d) | 1.8mA |
| 500V/1000V | 2MΩ -20GΩ | ±(5%+10d) | |
| 2000V/2500V | 5MΩ -40GΩ | ±(5%+10d) | |
| AC Voltage | 10-600V | ±(1%+5d) | |
| DC Voltage | 10-600V | ±(0.8%+5d) | |
| Resistance Range | 1MΩ -200GΩ | 100 Sets of Data Storage | √ |
| Max Count | 2000 Counts | HD Backlit Screen | √ |
| Use Battery | AA5 Battery *8 (not including) |
Absorption Ratio | √ |
| Material | Silica Gel/ABS | Polarization Index | √ |
| Weight | 640 G | Autoranging | √ |
| Test Lead Material | PVC/Brass | Automatic Discharge | √ |
| Overall Length of Test Leads |
108 CM | Test Voltage Display | √ |
| Back Support | √ | High Pressure Indication |
√ |
| Low Voltage Indication | √ | Measurement Time Display |
√ |
|
|
| MOQ: | 1pcs |
| Standard Packaging: | Paper pack |
| Delivery Period: | within 1~5days |
| Payment Method: | T/T, Western Union, MoneyGram, MoneyGram, MoneyGram, MoneyGram, MoneyGram |
| Supply Capacity: | 100000pcs |
Megger Instrumentation and devices Anti static system engineering
Insulation resistance tester (or high voltage insulation meter) is a special instrument for measuring insulation resistance. It is an ideal test instrument for measuring insulation resistance of large transformers, transformers, generators, high-voltage motors, power capacitors, power cables, arresters, etc.
| The Output Voltage | Measuring Range | Precision | Short circuit current |
| 250V | 1MΩ -10GΩ | ±(5%+10d) | 1.8mA |
| 500V/1000V | 2MΩ -20GΩ | ±(5%+10d) | |
| 2000V/2500V | 5MΩ -40GΩ | ±(5%+10d) | |
| AC Voltage | 10-600V | ±(1%+5d) | |
| DC Voltage | 10-600V | ±(0.8%+5d) | |
| Resistance Range | 1MΩ -200GΩ | 100 Sets of Data Storage | √ |
| Max Count | 2000 Counts | HD Backlit Screen | √ |
| Use Battery | AA5 Battery *8 (not including) |
Absorption Ratio | √ |
| Material | Silica Gel/ABS | Polarization Index | √ |
| Weight | 640 G | Autoranging | √ |
| Test Lead Material | PVC/Brass | Automatic Discharge | √ |
| Overall Length of Test Leads |
108 CM | Test Voltage Display | √ |
| Back Support | √ | High Pressure Indication |
√ |
| Low Voltage Indication | √ | Measurement Time Display |
√ |
