9965 000 10929 Shaft Head Assy Spline H1357 Without Bearing For Assembleon TopazXII/ Xii

9965 000 10929 Shaft Head Assy Spline H1357 Without Bearing For Assembleon TopazXII/ Xii

9965 000 10929 Shaft Head Assy Spline H1357 Without Bearing For Assembleon TopazXII/ Xii

Brand Name:	Assembleon
Model Number:	9965 000 10929
MOQ:	1pcs
Delivery Time:	within 3days
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand:

Assembleon

Part Name:

Shaft Head Sub ASSY

Part Number:

9965 000 10929

Length:

15CM

Material:

Metal

Condition:

New

Supply Ability:

10000pcs

Highlight:

9965 000 10929 Shaft Head Assy

,

H1357 Shaft Head Assy

Product Description

9965 000 10929 Shaft head Assy Spline H1357 without bearing For Assembleon TopazXII/ Xii

Detail Information:

1, Part Name: Shaft Head SUB Assy

2, Part Number: 9965 000 10929 / 996500010929

3, Machine: Topas XII

9965 000 10929 Shaft head Sub Assy

9965 000 10928 Shaft head sub assy

9965 000 10930 shaft head sub assy

Other Topaz Parts:

PHILIPS PART NUMBER ANDDESCRIPTIOM

5322 358 10173	Belt R-Axis Motor drive
5322 358 10174	Belt, R-Axis Spline
9965 000 09055	Belt, head
5322 358 10276	Belt
9965 000 10373	Pulley
5322 528 81507	Pulley Conveyor
5322 358 31283	Belt

5322 360 10323	Piston Assy (Piston cylinder only for HEAD 1)
5322 360 10206	Piston, Head Up Down Assembly Heads 1-8
5322 360 10481	Piston, Assembly Spline up down
5322 462 10762	Plug 2, assy (lower plug contains items 4,5,11)
5322 462 11201	Plug assy (plug assy 1-3-5-7)
9965 000 03801	Plug assy (plug assy 2-4-6-8)




5322 532 12547	Seal is located on the lower part of the piston shaft
5322 532 12545	Chevron seal used in Piston upper and lower plugs. Packing,
5322 532 12546	Chevron seal used in Piston assembly Packing
5322 532 13169	Packing
5322 530 51347	Packing,



5322 530 10289	O-ring, plugs
5322 530 51297	O-ring, metal caps
5322 530 10474	O-ring, plastic caps
5322 530 10292	O-ring, inlets
5322 530 10442	O-ring
5322 530 10441	O-ring


5322 502 60165	Screw (M2x3) leaf spring
5322 492 71713	Leaf spring
5322 492 11793	Leaf spring
5322 360 20081	Filter
5322 360 20106	MUFFLER
5322 530 70461	Circlip, shaft
5322 530 70526	CIRCLIP


5322 360 10207	Valve speed select
9965 000 03808	Valve, speed select
5322 360 10208	Valve up/down
9965 000 03807	Valve, up-down select
5322 693 11367	Single ejector
9965 000 09042	Ejector, Single
5322 360 10209	Valve blow-off
5322 281 20202	Single valve

5322 216 04084	Vacuum sensor board
5322 216 04673	Vacuum sensor board
5322 132 00141	Sensor, head down sensing
9965 000 10927	Sensor, head down sensing
5322 132 00036	Sensor Head
5322 132 00132	Sensor W origin
5322 132 00056	Sensor 1-3 (L=1150)
9965 000 06136	Sensor 1-3 (L=1400)
5322 130 10079	Sensor Presure

5322 693 11352	Spline assy (Complete spline shaft assy head 1)
5322 693 11199	Spline assy (Complete spline shaft heads 2-8, indicated with “Y” means 40 um accuracy)
5322 693 11539	Topaz Inner spline shaft heads 2-8
5322 693 11542	Inner Spline, 16 micron

5322 535 10674	Shaft head asyy (shaft head assy head 1-3-5-7 for SF and FNC head)
9965 000 03802	SHAFT NOZZLE HEAD
5322 535 10676	Shaft head assy (spline shaft assy 2-4-6-8 only for FNC head)

9965 000 10930	Spline Shaft, Even Heads, FNC
9965 000 10928	Spline Shaft, even Heads SF
9965 000 10929	Spline Shaft, Odd Heads SF and FNC

9965 000 10928	Spline Shaft, even Heads SF
9965 000 10929	Spline Shaft, Odd Heads SF and FNC



5322 216 04674	I/O Board for Topaz Xii (BD CNV)
9965 000 11067	I/O Core Board for Topaz Xii (BD)

5322 360 10483	Nozzle assy (nozzle assy heads 2-4-6-8)


5322 360 40523	Cylinder Main Stopper
5322 535 92541	Speed Controller
5322 360 40471	Cylinder sub stopper
5322 360 10205	Cylinder up/down
5322 526 40896	Joint
