KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W For Yamaha CL8mm Feeder

China KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W  For Yamaha CL8mm Feeder supplier
KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W  For Yamaha CL8mm Feeder supplier KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W  For Yamaha CL8mm Feeder supplier KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W  For Yamaha CL8mm Feeder supplier

Large Image :  KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W For Yamaha CL8mm Feeder

Product Details:

Place of Origin: China
Brand Name: Koganei
Model Number: BSA10*7-307W

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Delivery Time: within 3days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs
Contact Now
Detailed Product Description
Brand: Koganei Model: BSA10*7-307W
Part Name: Air Cylinder Part Number: KW1-M1185-00X
Application: CL8mm Feeder Origin: China

KW1-M1185-00X Koganei Air Cylinder BSA10*7-307W For Yamaha CL8mm Feeder



Description:

1, Brand: Koganei

2, Part Name: Air Cylinder

3, Part Number: KW1-M1185-00X

4, Model: BSA10x7-307W

5, Application: Yamaha CL8mm Feeder



KW1-M1185-00X Koganei Multi Cylinder BSA10*7-307W  For Yamaha CL8mm Feeder



1 K87-M111H-20X BACK STOPPER 1
2 K87-M111B-00X BACK STOPPER AXIS 1
3 KW1-M111A-00X SPRING 1
4 K87-M111G-10X PUSH PIN 1
5 K87-M111C-00X PLANE WASHER 1
6 K87-M111P-00X SCREW,FLAT HEAD + 1
7 K87-M111D-00X PUSH PIN 1
8 K87-M112L-10X SPROCKET AXIS ASSY 1
9 KW1-M112A-00X RACKING LEVER ASSY 1
10 K87-M112D-10X COIL SPRING 1
11 KW1-M111E-00X SPRING 1
12 K87-M111F-10X STOPPER PIN 1
13 K87-M1181-00X ROD CONNECT 1
14 K87-M1184-00X CONNECT PIN 1
15 KW1-M1185-00X MULTI CYLINDER 1
16 KW1-M111L-00X BARB CONNECTOR 2
17 K87-M111M-00X GASKET 2
18 KW1-M11B1-00X AIR HOSE 1 L70
19 K87-M11B9-00X CIRCLIP E 1
20 KW1-M11BL-00X BOLT,HEX SOCKET HEAD 2
21 KW1-M11BM-00X SPRING LOCK WAHSER 2
22 KW1-M114A-00X HAND LEVER ASSY 1
23 KW1-M116K-00X LEVER AXIS 1
24 KW1-M1177-00X MAIN ARM 1
25 K87-M111C-00X PLANE WASHER 2
26 K87-M11BF-00X SCREW,FLAT HEAD +IB 2
27 KW1-M114N-00X GUIDE AXIS 1
28 K87-M111R-00X SCREW,SET 5
29 K87-M111T-00X SCREW,SET 1
30 K87-M1120-10X SPROCKET ASSY 1
31 KW1-M1140-00X TAPE GUIDE ASSY 1
No. Part No. Part Name Qty Remarks Date Revised No.
1 KW1-M1110-00X BODY ASSY 1
2 KW1-M1112-00X KNOCK PIN 1 FRONT
3 KW1-M1113-00X KNOCK PIN 1 REAR
4 K87-M1115-00X CIRCULAR RIVET 2
5 KW1-M1150-00X HANDLE LEVER ASSY 1
6 KW1-M116F-00X LEVER AXIS PIN 1
7 KW1-M115D-00X GUIDE PIN ASSY 1
8 KW1-M116D-00X TENSION LEVER ASSY 1
9 KW1-M116F-00X LEVER AXIS PIN 1
10 K87-M1115-00X CIRCULAR RIVET 2
11 KW1-M1131-00X CLAMP LEVER UNIT 1
12 KW1-M1132-00X CLAMP LEVER ASSY 1
13 K87-M113A-00X CLANK ARM ASSY 1
14 K87-M113D-00X ARM 2
15 K87-M113E-00X HINGE PIN 2 1
16 K87-M11D7-00X CIRCLIP E 2
17 K87-M113L-10X CLAMP LEVER AXIS 1
18 K87-M113M-00X AXIS PIN 1
19 K87-M113H-00X PUSH PIN 1
20 K87-M111V-00X SCREW,SET 1
21 K87-M111R-00X SCREW,SET 1
22 KW1-M114L-00X COVER 1
23 KW1-M111T-00X SCREW,THIN HEAD 3
24 KW1-M116J-00X METAL SHAFT 1
25 K87-M11BA-00X SCREW,FLAT HEAD + 3
26 KW1-M1191-00X DRIVE ROLLER UNIT 1
27 KW1-M1192-00X INDENTATION LVR ASSY 1
28 KW1-M119F-00X DRIVE ROLLER ASSY 1
29 K87-M117B-00X PLANE WASHER 1
30 K87-M11BB-00X SCREW,FLAT HEAD + IB 1
31 KW1-M119K-00X SPRING 1
32 KW1-M119L-00X IDLE ROLLER ASSY 1
33 KW1-M119R-00X COLLAR 1
34 K87-M21BB-00X SCREW,TRUSS HEAD 1
35 KW1-M119P-00X SPRING 1
36 KW1-M11A1-00X LOWER GUIDE PLATE R 1
37 K87-M53BS-00X SCREW,PAN HEAD + 2
38 KW1-M11A3-00X LOWER GUIDE PLATE L 1
39 K87-M111N-00X SCREW,PAN HEAD + 2
40 KW1-M115L-00X HOLD ARM 1 BLACK
41 KW1-M115M-00X ARM AXIS
No. Part No. Part Name Qty Remarks Date Revised No.
1 KW1-M11D1-00X REEL HOLDER ASSY 1
2 KW1-M111S-00X SCREW,FLAT HEAD + 1
3 K87-M111S-00X SCREW,FLAT HEAD + 2
